Floor markings have a job to do. They identify walkways, define safety zones, separate traffic areas, and help keep busy facilities organized. When those markings are exposed to forklifts, equipment, chemicals, cleaning, and constant foot traffic, the coating used to create them matters.
That is where epoxy safety lines come in.
515 now carries LABPOX® SAFETY LINES from LabSurface, expanding the LABPOX product lineup available through 515. The system is a 100% solids, two-component, self-priming epoxy developed specifically for concrete floor safety-zone and corridor marking.
What Are Epoxy Safety Lines?
Epoxy safety lines are high-performance floor coatings used to create durable, highly visible markings on concrete surfaces. Unlike basic floor paint, a purpose-built safety marking epoxy is designed around the conditions those markings have to withstand.
Applications can include:
- Safety floor lines and zone markings
- Pedestrian walkways
- Equipment and machinery zones
- Warehouse and distribution areas
- Manufacturing facilities
- Commercial and institutional facilities
- Parking garages
- Healthcare and educational facilities
LABPOX SAFETY LINES is designed for commercial, industrial, and institutional environments where floor markings need to remain visible while handling demanding service conditions.
Why Use Epoxy for Safety Markings?
The challenge with epoxy safety line markings is not putting a line on concrete. It is keeping that line intact.
Industrial and commercial floors see abrasion, traffic, cleaning, chemical exposure, and repeated maintenance. LABPOX SAFETY LINES is formulated with cycloaliphatic polyamine technology and provides mechanical and chemical properties suited to demanding applications. Its technical data also reports 100% solids by volume, 0 g/L VOC content, 85 Shore D hardness at maturity, and abrasion resistance of 55 mg loss under ASTM D4060 testing.
For the applicator, the system is also designed around getting the marking down efficiently.
One-Coat Application With High Opacity
LABPOX EPOXY SAFETY LINES is formulated for high opacity and full coverage at approximately 10 mils. LabSurface states that the product can provide approximately three times the coverage of regular pre-tinted epoxy, allowing a safety marking to be completed in a single application.
The product is available in bright safety colors including yellow, red, blue, green, and orange. That gives applicators flexibility when a project requires multiple colors for different zones or markings.
Crisp EPOXY SAFETY Lines Matter
Anyone who has installed floor markings knows that getting the line straight is only part of the job. Keeping the coating from bleeding beneath the tape is what produces a clean finished line.
LABPOX SAFETY LINES incorporates what LabSurface calls Crisp Line Technology, designed to prevent the coating from leaching under masking tape during application. The result is a cleaner edge without relying on multiple coats to build opacity.
For experienced applicators, that can make a difference in both appearance and production time.
Built for More Than Warehouse Floors
Safety markings are common in warehouses and manufacturing facilities, but the need for durable floor identification extends well beyond those environments.
LabSurface lists applications including food and beverage, pharmaceutical, automotive and recreational vehicle facilities, commercial and retail spaces, distribution centers, healthcare, schools, public buildings, sports facilities, offices, and parking garages.
The system can also be applied horizontally or vertically, expanding its use beyond standard floor striping.
Technical Characteristics
For projects where specifications matter, LABPOX SAFETY LINES is a 3A:1B, 100% solids epoxy with a self-priming formulation. LabSurface’s technical information identifies a 30-minute working time, approximately four-hour tack-free time, 24-hour foot traffic, 48-hour light traffic, and one-week full cure under the stated test conditions.
Application conditions, substrate preparation, mixing, and cure times should always be evaluated against the current technical data sheet and the conditions of the individual project.
Available Through 515
515 has worked with LabSurface systems for more than seven years. LABPOX SAFETY LINES expands that lineup with a purpose-built option for projects where floor markings need more than color alone.
For applicators evaluating an epoxy safety line system, the important questions are straightforward: What will the marking be exposed to? How much traffic will it see? What level of opacity is required? How quickly does the area need to return to service? And what application method makes sense for the project?
Those are the questions 515 can help work through before the material ever reaches the floor.
LABPOX SAFETY LINES is now available through 515 Decorative Concrete Supply.
